SG26505
SANGAS
SG series batteries are specially developed and produced for high quality MWD / LWD, which is safe and reliable, with stable performance, meanwhile it can be customized according to customer's request.
٭ Stable performance, safe and reliable
٭ Can adapt to various harsh environments
٭ High temperature
٭ Can be customized
High Temperature Lithium Battery Specifcations:
Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Max. operating current (mA) | Diameter (mm) | Height (mm) | Approx. Weight (g) | Operational Temp (C) |
SG32127 | 3.6V | 27Ah | 1200mA | 32mm | 127mm | 215g | -40~+165℃ |
SG32615 | 3.6V | 11Ah | 1200mA | 32mm | 61.5mm | 110g | -40~+165℃ |
SG26750 | 3.6V | 7.5Ah | 400mA | 26mm | 75mm | 90g | -40~+165℃ |
SG26100 | 3.6V | 13Ah | 600mA | 26mm | 100mm | 120g | -40~+165℃ |
SG26505 | 3.6V | 5.5Ah | 400mA | 26mm | 50.5mm | 60g | -40~+165℃ |
SG20100 | 3.6V | 6.0Ah | 200mA | 20mm | 100mm | 50g | -40~+165℃ |
SG18505 | 3.6V | 2.2Ah | 150mA | 18mm | 50.5mm | 28g | -40~+165℃ |
SG14505 | 3.6V | 1.76Ah | 60mA | 14mm | 50.5mm | 16g | -40~+165℃ |
SG14505s | 3.6V | 1.6Ah | 50mA | 13.8mm | 50mm | 15g | -40~+165℃ |
SG38850 | 3.6V | 24Ah | 800mA | 38mm | 85mm | 200g | -40~+165℃ |
SG4880 | 3.6V | 34Ah | 2000mA | 48mm | 80mm | 310g | -40~+165℃ |
